- Frame
- Carbon monocoque RTM frame with steering head angle and swinging-arm pivot adjustment, load-bearing engine
- Vering voor
- Öhlins FGR 300 WSBK fork, adjustable rebound and compression-stage damping, adjustable spring preload, Öhlins SD052 adjustable steering damper, front wheel quick-change system thanks to rotatable forklegs with front-wheel cover mounted (brake calipers need not be removed to change a wheel) spring stiffness 10.5 N/mm
- Vering achter
- Aluminium WSBK swinging arm, Öhlins TTX 36 GP central spring strut, adjustable rebound and compression-stage damping, adjustable spring preload, top spring strut pivot point adjustable (0/3 mm), adjustable spring strut deflection (tension strut length), contact surfaces for wheel spacer bush on chain tensioners for simple/hands free wheel fitting, chain tensioner titanium on outside, aluminium on inside, CFRP auxiliary stand mountings on swinging arm, spring stiffness 95N/mm
- Remmen voor
- 2 x Brembo Racing disc brake, T-floating racing brake discs, 320×6.75 mm diameter, 4-piston monobloc WSBK GP4-PR fixed caliper with titanium pistons, Brembo Racing RCS19X18 master cylinder, including adjustable Brembo Racing brake lever, Brembo Racing clutch lever (without clutch switch)
- Remmen achter
- Single Brembo Racing disc brake, 4-piston WSBK fixed caliper with titanium pistons, brake disc diameter 220×4.0 mm Dimensions / weights
- Voorband
- 120/70 ZR 17 Pirelli Diabolo Superbike Slick SC2
- Achterband
- 200/60 ZR 17 Pirelli Diabolo Superbike Slick SC2
- Wielbasis
- 1.440 mm
