- Frame
- Aluminum dual beam chassis with removable seat-supporting subframe
- Vering voor
- Kayaba 41 mm USD fork with top out spring, Aluminum pins to fasten radial calipers. Rebound and spring preload adjustment on a single stanchion
- Vering achter
- Asymmetrical aluminum swingarm. Single shock and top out spring with rebound and spring pre-load adjustment
- Remmen voor
- 2x 320mm Brembo radial calipers with 4 horizontally opposed 32 mm pistons. Radial pump and metal braided brake hose
- Remmen achter
- Single 220mm disc; Brembo caliper with two 34 mm separate pistons. Master cylinder with separate reservoir and metal braided hose Multimap ABS (Cornering ABS available as optional accessory)
- Voorband
- 120/70 ZR 17 Tubeless radials
- Achterband
- 180/55 ZR 17 (alternatively 180/60 ZR17) Tubeless radials
- Wielbasis
- 1.370 mm
